Coffee Vending Machines

Azkoyen – Zintro

Technical specifications
Zen 5 espresso  Zen espresso  Zen 5 instant Zen 6 instant
Capacity Configuration: Coffee bean hoppers: 1 Soluble canisters: 4 Single: 1 Double: 1 Asymmetric: 2 Cups: 320 Coffee bean hoppers: 1 Soluble canisters: 5 Single: 1 Double: 0 Asymmetric: 4 Cups: 320 Coffee bean hoppers: - Soluble canisters: 5 Single: 2 Double: 1 Asymmetric: 2 Cups: 320 Coffee bean hoppers: - Soluble canisters: 6 Single: 2 Double: 0 Asymmetric: 4 Cups: 320
Product Capacity Coffee beans: 1,9 Kg Soluble coffee: 0,4 Kg Soluble milk: 2,2 Kg Chocolate: 2,2 Kg Soluble tea: - Sugar: 2,6 Kg Coffee beans: 1,9 Kg Soluble coffee: 0,4 Kg Soluble milk: 1,6 Kg Chocolate: 2,2 Kg Soluble tea: 1 Kg Sugar: 2,6 Kg Coffee beans: - Soluble coffee: 0,8 + 0,4 Kg Soluble milk: 1,6 Kg Chocolate: 2,2 Kg Soluble tea: 1Kg Sugar: 2,6 Kg Coffee beans: - Soluble coffee: 0,8 Kg Soluble milk: 2,2 Kg Chocolate: 2,2 Kg Soluble tea: 1 Kg Sugar: 2,6 Kg
Brewing systems Type: Espresso Capacity: 8 gr. Name of the Group: Espresso Azk V10 Number of mixers: 2/3 Type: Instant Number of mixers: 3/4
Grinder Name of the grinder: VPTT Vending Performance Number of grinders: 1
Boiler Type: Pressure Capacity volume: 315 cc
Selections and pre-selections Type of selection interface : touch keypad Selections: 4 Pre-selections: 8
Connectivity and communications RS232
Sensors and Filters Out of Coffee detector Blocked grinder detector Electronic water temperature control. Electronic water level control. Optional cup detector
Dimensions and weight Height: 740 mm Width: 480 mm Depth: 590 mm Weight: 65-70 kg
Energy Voltage: 230 V/50 Hz Maximum Power: 1800W

Azkoyen – Zen

Technical specifications  Technical specifications
Zintro 5 Espresso Zintro Instant
Capacity Setting: No. coffee bean hoppers: 1 No. soluble hoppers: 4+1 Singles: 1 Doubles: 0 Asymmetrical: 4 No. 70 mm cups: 500 No. coffee bean hoppers: - No. soluble hoppers: : 6 Singles: 2 Doubles: 0 Asymmetrical: 4 No. 70 mm cups: 500
Product Capacity Recommended Configuration Coffee beans: 2.6 Kg Soluble tea: 1.3 Kg Soluble milk: 2.6 Kg Chocolate: 3.0 Kg Decaffeinated coffee: 0.6 Kg Sugar: 3.5 Kg Soluble tea: 1,3 Kg Soluble milk: 2,6 Kg Chocolate: 3,0 Kg Decaffeinated coffee: 0,6 Kg Sugar: 3,5 Kg Soluble coffee: 1,2 Kg
Dispensing Systems System type: Espresso Capacity: 8 gr. Group name: Azk V10 No. whisks: 3 System type: Instant No. whisks: 4
Grinder Name of grinder: : VPTT Vending Performance No. of grinders: 1
Boiler Type: Pressure Volume capacity: 315 cc
Selections and pre-selections Interface selection type: Azkoyen Touch Keypad No. of pre-selections: 4 No. of selections: 8
Connectivity and communications Protocol EXE/MDB RS-232 USB connection kit available
Sensors and Filters Out of coffee detector Blocked grinder detector Water temperature control Water level control Optional cup detector
Dimensions and weight Height: 1620 mm Width: 480 mm Depth: 590 mm Weight: 100 Kg
Energy Voltage: 220~230 V 50/60 Hz - 110~127 V 50/60 Hz Maximum Power: 1800 W | Maximum Power: 2100 W Eco Mode: Yes
Colour Black / Various designs
